Yanmar
We have made an overview where you can easily find which parts you need for your model of a Yanmar inboard engine.
The table below makes it easy to see which part numbers you need for your model Yanmar engine:
| ENGINE MODEL |
OIL FILTER |
FUEL FILTER |
AIR FILTER |
ANODE ZINC |
IMPELLER |
| 1GM | 119305-35151 | 104500-55710 | 128170-12540 | 128176-42071 | |
| 1GM10 | 119305-35151 | 104500-55710 | 128171-12540 | 27210-200200 | 128176-42071 |
| 2GM/3GM | 119305-35151 | 104500-55710 | 128270-12540 | 27210-200300 | 104211-42070 |
| 2GMF/3GMF | 119305-35151 | 104500-55710 | 128270-12540 | 27210-200300 | 128296-42070 |
| 2GM20-YEU | 119305-35151 | 104500-55710 | 128270-12540 | 27210-200300 | 128990-42200 |
| 2GM20F-YEU | 119305-35151 | 104500-55710 | 128270-12540 | NA | 128990-42200 |
| 2GM20/3GM30 | 119305-35151 | 104500-55710 | 128270-12540 | 27210-200300 | 104211-42070 |
| 2GM20F/3GM30F | 119305-35151 | 104500-55710 | 128270-12540 | NA | 104211-42070 |
| 2QM | 124770-12540 | 27210-200300 | 128296-42070 | ||
| 2QM15 | 119305-35151 | 104500-55710 | 124770-12540 | 27210-200300 | 104211-42070 |
| 3QM | 124770-12540 | 27210-200300 | 145410-46050 | ||
| 2QM20/3QM30 | 104500-55710 | 124770-12540 | 27210-200300 | 128296-42070 | |
| 2YM15 | 119305-35151 | 104500-55710 | 128270-12540 | NA | 128990-42200 |
| 3YM20© | 119305-35151 | 104500-55710 | 128270-12540 | NA | 128990-42200 |
| 3YM30(C) | 119305-35151 | 104500-55710 | 128270-12540 | NA | 128990-42200 |
| 3GM30-YEU | 119305-35151 | 104500-55710 | 128270-12540 | 27210-200300 | 128990-42200 |
| 3GM30F-YEU | 119305-35151 | 104500-55710 | 128270-12540 | NA | 128990-42200 |
| 3HM | REC124550-35110 | 104500-55710 | 124770-12540 | 27210-200300 | 128296-42070 |
| 3HMF | REC124550-35110 | 104500-55710 | 124770-12540 | NA | 128296-42070 |
| 3HM35 | REC124550-35110 | 104500-55710 | 124770-12540 | 27210-200300 | 128296-42070 |
| 3HM35F | 104500-55710 | 124770-12540 | NA | 128296-42070 | |
| 3JH2E | 119305-35151 | 129470-55703 | (K) | NA | 129470-42532 |
| 3JH2-TE | 119305-35151 | 129470-55703 | 129470-12330 | NA | 129470-42532 |
| 3JH3E-YEU | 119305-35151 | 129470-55703 | (K) | NA | 129670-42531 |
| 3JH4E | 119305-35151 | 129470-55703 | NA | NA | 129670-42531 |
| 3JH5E | 119305-35151 | NA | NA | ||
| 4JHE/4JH-TE | 129150-35153 | 129470-55703 | 129470-12330(K) | NA | 129470-42532 |
| 4JH-HTE/-DTE | 129150-35153 | 129470-55703 | NA | NA | 129470-42532 |
| 4JH2E/4JH2-TE | 129150-35153 | 129470-55703 | 129470-12330(K) | NA | 129470-42532 |
| 4JH2-HTE/-DTE | 129150-35153 | 129470-55703 | 129470-12330 | NA | 129470-42532 |
| 4JH2-UTE(B) | 129150-35153 | 129574-55711 | 129470-12330 | NA | 129470-42532 |
| 4JH3E-YEU | 129150-35153 | 129470-55703 | (K) | NA | 129670-42531 |
| 4JH3-TE/-HTE/-DTE | 129150-35153 | 129574-55711 | 129470-12330 | NA | 129670-42531 |
| 4JH4E | 129150-35153 | 129574-55703 | NA | NA | 129670-42531 |
| 4JH4AE | 129150-35153 | NA | NA | 129670-42531 | |
| 4JH4-T-THE-DTE | 129150-35153 | 129574-55711 | (K) | NA | |
| 4JH5E | 129150-35153 | NA | NA | ||
| 4LH-TE/-HTE | 119005-35100 | 121857-55710(O) | NA | 120650-42310 | |
| 4LH-DT/ST(Z)E | 127695-35150 | 41650-502320 | 120650-42310 | ||
| 4LHA-DT(Z)(E)(P) | 127695-35150 | 41650-502320 | 119195-18880 | 119574-44150-01 | 120650-42310 |
| 4LHA-HT(Z)(E)(P) | 127695-35150 | 121857-55710(O) | 119195-18880 | 119574-44150-01 | 120650-42310 |
| 4LHA-ST(Z)(E)(P) | 127695-35150 | 41650-502320 | 119574-44150-01 | 120650-42310 | |
| 4BY (2) | 165000-69520 | ||||
| 6BY (2) | 165000-69590 | ||||
| 6LPA-STP2(3) | 119770-90620 | 119593-18880 | 119574-44150 | 119773-42600 | |
| 6LP-DT(Z)E/-ST(Z) | 119770-90620 | 119574-44150 | 119773-42600 | ||
| 6LPA-D/ST(Z)(E)(P) | 119770-90620 | 119574-44150 | 119773-42600 | ||
| 6LY-UTE/-STE | 119593-35100 (A) | 41650-502330 | 119593-18880 | 119574-44150 | 119593-42201 |
| 6LYA-UTE/-STE | 119593-35100 | 41650-502330 | 119593-18880 | 119574-42551 | |
| 6LY2A-ST(E)(P) | 119593-35100 (A) | 41650-502330 | 119593-18880 | 119574-44150 | 119574-42551 |
| 6LY3-ETP | 119593-35100 (A) | 41650-502330 | 119593-18880 | 27210-200200 | 119574-42551 |
| 6CX-ETE | 127695-35150(B) | 127695-55630 | 128620-42200 | ||
| 6CX-GTE(2) | 127695-35150(A) | 127695-55630 | 127692-18880 | 128620-42200 | |
| 6CX530 | 127695-35150 (B)(A) | ||||
| 6CXBM-GT | 127695-35150 (B)(A) | 127695-55630 | 127692-18880 |
