Electric Start Control Box Assembly
| Nummer: |
Bestelnummer: |
OEM: |
Omschrijving: |
| 1 |
PAF25-11000000W |
|
CONTROL BOX ASS‘Y |
| 2 |
PAHT2.5*60 |
|
CLAMP |
| 3 |
PAF15-13000200W |
703-82510-12 |
STARTING SWICH ASS’Y |
| 4 |
PAF15-13000100W |
|
CONTROL CABLE ASS‘Y(5M=16.4’) |
| 5 |
PAF15-11000002W |
|
PLATE,CONTROL BOX |
| 6 |
PAGB/T819.2-1997 |
|
SCREW PAN HEAD M5X12 |
| 7 |
PAF15-13020007W |
|
THROTTLE HANDLE, INCHING |
| 8 |
PAF15-13000005W |
|
BUSH, CAM |
| 9 |
PAF15-13020006W |
|
BUSH, HANDLE |
| 10 |
PAF15-11000001W |
|
BLOCK, RUBBER |
| 11 |
PAF15-13000014W |
|
JACKET, CABLE |
| 12 |
PAF4-01090401 |
682-82556-00 |
STOPER,HANG ROPE ASS’Y |
| 13 |
PAF15-13020400W |
|
ENGINE STOP SWICH ASS’Y |
| 14 |
PAF15-13000203W |
90464-09M13 |
INSULATED PLUG ‘’B’’ |
| 15 |
PAF15-13000202W |
|
INSULATED PLUG ‘’A’’ |
| 16 |
PAF15-13020001W |
|
COVER, CONTROL BOX |
| 17 |
PAF15-13000013W |
|
SMALL COVER, CONTROL BOX |
| 18 |
PAF15-13020005W |
|
WASHER “B”, WAVE |
| 19 |
PAF15-13020100W |
|
LOCKED DISK ASS‘Y |
| 20 |
PAF15-13020002W |
|
TORSION SPRING |
| 21 |
PAF15-13020003W |
|
EACH LOCKED PULLEY |
| 22 |
PAF15-13020004W |
|
PLATE, PULLEY SPRING |
| 23 |
PAGB/T818-2000 |
|
PAN HEAD SCREW M4X6 |
| 24 |
PAF15-13020000W |
|
COVER ASS‘Y, CONTROL BOX |
| 25 |
PAGB/T5783-2000 |
68D-E5362-00 |
BOLT M8X30 |
| 26 |
PAGB/T97.1-85 |
66M-11327-00-94 |
WASHER 8 |
| 27 |
PAF15-13000500W |
|
MACHINE, CONTROL ACCELEROGRAPH |
| 28 |
PAF15-13000007W |
|
WASHER |
| 29 |
PAGB/T896-1986 |
|
PINCOTTER 6 |
| 30 |
PAF25-07000007W |
|
CONTROL CABLE TIE IN “B” |
| 31 |
PAF15-13000002W |
|
CAM MECHANISM |
| 32 |
PAGB/T818-2000 |
|
PAN HEAD SCREW M3X14 |
| 33 |
PAF15-13000800W |
|
INCHING SWITCH |
| 34 |
PAF15-13000003W |
|
PLATE |
| 35 |
PAF15-13000004W |
|
PULLEY |
| 36 |
PAF15-13000001W |
|
SHIFT SPRING PLATE “B” |
| 37 |
PAF15-12000016W |
|
MARK 16 |
| 38 |
PAGB/T6170-2000 |
95380-08600 |
NUT M6 |
| 39 |
PAF15-13000008W |
|
WEARABLE PLATE, CAM MACHANISM |
| 40 |
PAF15-13000700W |
|
SHIFT SWING LINK |
| 41 |
PAF15-13000601W |
|
ADJUSTER FASTNESS ASS’Y |
| 42 |
PAGB/T5783-2000 |
68D-E5362-00 |
BOLT M5X25 |
| 43 |
PAGB/T6170-2000 |
95380-08600 |
NUT M5 |
| 44 |
PAF15-13000300W |
|
BUZZER ASS‘Y |
| 45 |
PAF15-13000602W |
|
ADJUSTER PIN |
| 46 |
PAGB/T5287-1985 |
92990-06600 |
BIG WASHER 6 |
| 47 |
PAF15-13000006W |
|
WEARABLE PLATE |
| 48 |
PAF15-13000011W |
|
BUSH, SHIFT SWING LINK |
| 49 |
PAF15-13000012W |
|
BRACKET, CONTROL BOX |
| 50 |
PAF15-12000013W |
|
MARK 13 |
| 51 |
PAF15-13000015W |
|
COVER, WATERPROOF |
| 52 |
PAF15-13010010W |
|
BLOCK, CONTROL HANDLE |
| 53 |
PAGB/T956.1-1987 |
|
WASHER, LOCKED 5 |
| 54 |
PAGB/T819.2-1997 |
|
SCREW, PAN HEAD M5X18 |
| 55 |
PAF15-13010003W |
|
JAM, BUTTON |
| 56 |
PAF15-13010001W |
|
CONTROL HANDLE |
| 57 |
PAF15-13010002W |
|
CONTROL HANDLEBAR |
| 58 |
PAGB/T84.5-2000 |
|
SCREW, PAN HEAD ST4.8X12 |
| 59 |
PAGB/T818-2000 |
|
SCREW, PAN HEAD M4X10 |
| 60 |
PAF15-13010009W |
|
COVER, CONTROL HANDLE |
| 61 |
PAF15-13010005W |
|
SPRING, COMPRESSION |
| 62 |
PAF15-13010004W |
|
PART, ORIENTATION CONTROL |
| 63 |
PAF15-13010008W |
|
PLATE, ORIENTATION PART |
| 64 |
PAGB/T820-2000 |
|
SCREW, PAN HEAD M6X90 |
| Number: |
Order number: |
OEM: |
Description: |
| 1 |
PAF25-11000000W |
|
CONTROL BOX ASS‘Y |
| 2 |
PAHT2.5*60 |
|
CLAMP |
| 3 |
PAF15-13000200W |
703-82510-12 |
STARTING SWICH ASS’Y |
| 4 |
PAF15-13000100W |
|
CONTROL CABLE ASS‘Y(5M=16.4’) |
| 5 |
PAF15-11000002W |
|
PLATE,CONTROL BOX |
| 6 |
PAGB/T819.2-1997 |
|
SCREW PAN HEAD M5X12 |
| 7 |
PAF15-13020007W |
|
THROTTLE HANDLE, INCHING |
| 8 |
PAF15-13000005W |
|
BUSH, CAM |
| 9 |
PAF15-13020006W |
|
BUSH, HANDLE |
| 10 |
PAF15-11000001W |
|
BLOCK, RUBBER |
| 11 |
PAF15-13000014W |
|
JACKET, CABLE |
| 12 |
PAF4-01090401 |
682-82556-00 |
STOPER,HANG ROPE ASS’Y |
| 13 |
PAF15-13020400W |
|
ENGINE STOP SWICH ASS’Y |
| 14 |
PAF15-13000203W |
90464-09M13 |
INSULATED PLUG ‘’B’’ |
| 15 |
PAF15-13000202W |
|
INSULATED PLUG ‘’A’’ |
| 16 |
PAF15-13020001W |
|
COVER, CONTROL BOX |
| 17 |
PAF15-13000013W |
|
SMALL COVER, CONTROL BOX |
| 18 |
PAF15-13020005W |
|
WASHER “B”, WAVE |
| 19 |
PAF15-13020100W |
|
LOCKED DISK ASS‘Y |
| 20 |
PAF15-13020002W |
|
TORSION SPRING |
| 21 |
PAF15-13020003W |
|
EACH LOCKED PULLEY |
| 22 |
PAF15-13020004W |
|
PLATE, PULLEY SPRING |
| 23 |
PAGB/T818-2000 |
|
PAN HEAD SCREW M4X6 |
| 24 |
PAF15-13020000W |
|
COVER ASS‘Y, CONTROL BOX |
| 25 |
PAGB/T5783-2000 |
68D-E5362-00 |
BOLT M8X30 |
| 26 |
PAGB/T97.1-85 |
66M-11327-00-94 |
WASHER 8 |
| 27 |
PAF15-13000500W |
|
MACHINE, CONTROL ACCELEROGRAPH |
| 28 |
PAF15-13000007W |
|
WASHER |
| 29 |
PAGB/T896-1986 |
|
PINCOTTER 6 |
| 30 |
PAF25-07000007W |
|
CONTROL CABLE TIE IN “B” |
| 31 |
PAF15-13000002W |
|
CAM MECHANISM |
| 32 |
PAGB/T818-2000 |
|
PAN HEAD SCREW M3X14 |
| 33 |
PAF15-13000800W |
|
INCHING SWITCH |
| 34 |
PAF15-13000003W |
|
PLATE |
| 35 |
PAF15-13000004W |
|
PULLEY |
| 36 |
PAF15-13000001W |
|
SHIFT SPRING PLATE “B” |
| 37 |
PAF15-12000016W |
|
MARK 16 |
| 38 |
PAGB/T6170-2000 |
95380-08600 |
NUT M6 |
| 39 |
PAF15-13000008W |
|
WEARABLE PLATE, CAM MACHANISM |
| 40 |
PAF15-13000700W |
|
SHIFT SWING LINK |
| 41 |
PAF15-13000601W |
|
ADJUSTER FASTNESS ASS’Y |
| 42 |
PAGB/T5783-2000 |
68D-E5362-00 |
BOLT M5X25 |
| 43 |
PAGB/T6170-2000 |
95380-08600 |
NUT M5 |
| 44 |
PAF15-13000300W |
|
BUZZER ASS‘Y |
| 45 |
PAF15-13000602W |
|
ADJUSTER PIN |
| 46 |
PAGB/T5287-1985 |
92990-06600 |
BIG WASHER 6 |
| 47 |
PAF15-13000006W |
|
WEARABLE PLATE |
| 48 |
PAF15-13000011W |
|
BUSH, SHIFT SWING LINK |
| 49 |
PAF15-13000012W |
|
BRACKET, CONTROL BOX |
| 50 |
PAF15-12000013W |
|
MARK 13 |
| 51 |
PAF15-13000015W |
|
COVER, WATERPROOF |
| 52 |
PAF15-13010010W |
|
BLOCK, CONTROL HANDLE |
| 53 |
PAGB/T956.1-1987 |
|
WASHER, LOCKED 5 |
| 54 |
PAGB/T819.2-1997 |
|
SCREW, PAN HEAD M5X18 |
| 55 |
PAF15-13010003W |
|
JAM, BUTTON |
| 56 |
PAF15-13010001W |
|
CONTROL HANDLE |
| 57 |
PAF15-13010002W |
|
CONTROL HANDLEBAR |
| 58 |
PAGB/T84.5-2000 |
|
SCREW, PAN HEAD ST4.8X12 |
| 59 |
PAGB/T818-2000 |
|
SCREW, PAN HEAD M4X10 |
| 60 |
PAF15-13010009W |
|
COVER, CONTROL HANDLE |
| 61 |
PAF15-13010005W |
|
SPRING, COMPRESSION |
| 62 |
PAF15-13010004W |
|
PART, ORIENTATION CONTROL |
| 63 |
PAF15-13010008W |
|
PLATE, ORIENTATION PART |
| 64 |
PAGB/T820-2000 |
|
SCREW, PAN HEAD M6X90 |
