Electric Oil Pump
| NR: |
Bestelnummer: |
OEM: |
Omschrijving |
Aantal: |
| 1 |
PAF40-05000069EI |
|
AIR PIPE C |
1 |
| 2 |
PAT5-04000200 |
|
CHECK VALVE |
1 |
| 3 |
PAF40-05000070EI |
|
AIR PIPE D |
2 |
| 4 |
PAF15-05000011 |
688-24378-00 |
THREE WAY |
1 |
| 5 |
PAF40-05000051EI |
|
AIR PIPE B |
1 |
| 6 |
PAF40-05100000EI |
|
OIL PUMP ASSY |
1 |
| 7 |
PAF40-05010400EI |
|
JOINT ASSY, OIL PUMP |
1 |
| 8 |
PAGB/T3452.1-15.8x3.1 |
|
O-RING 15.8x3.1 |
1 |
| 9 |
PAF40-05100100EI |
892267T57 |
BODY ASSY, OIL PUIIP |
1 |
| 10 |
PAF40-05100100EI |
|
SINGLE LUG CLAMP |
4 |
| 11 |
PAF40-05100010EI |
|
SHAPED TUBE A, OIL PUMP |
1 |
| 12 |
PAF40-05100010EI |
|
SHAPED TUBE B, OIL PUMP |
1 |
| 13 |
PAF40-05100202EI |
883220 |
CAP, DETECTION VALVE |
1 |
| 14 |
PAF40-05100201EI |
|
DETECTION VALVE, OIL PUMP |
1 |
| 15 |
PAF40-05100600EI |
|
PRESSURE REGULATOR VALVBE |
1 |
| 16 |
PAF40-05100601EI |
|
O-RING, PRESSURE REGULATOR VALVE |
1 |
| 17 |
PAF40-05100600-1EI |
|
WASHER, PRESSURE REGULATOR VALVE |
2 |
| 18 |
PAF40-05100602EI |
|
CONDUIT TUBE |
1 |
| 19 |
PAF40-05100603EI |
|
PLATE, PRESSURE REGULATOR VALVE |
1 |
| 20 |
PAGB/T818-M5x12 |
97885-05012 |
SCREW M5x12 |
2 |
| 21 |
PAGB/T818-M4x16 |
|
SCREW M4x16 |
5 |
| 22 |
PAGB/T93-4 |
|
SPRING WASHER 4 |
5 |
| 23 |
PAF40-05100301EI |
892267A52 |
NEEDLE VALVE |
1 |
| 24 |
PAF40-05100302EI |
|
CLAMP SPRING, NEEDLE VALVE |
1 |
| 25 |
PAF40-05100003EI |
|
BAFFLE PLATE |
1 |
| 26 |
PAGB/T818-M4x8 |
|
SCREW M4x8 |
4 |
| 27 |
PAF40-05100001EI |
892267527 |
FLOATER |
1 |
| 28 |
PAF40-05100002EI |
892267528 |
PIN, FLOATER |
1 |
| 29 |
PAF40-05100500EI |
892267A51 |
OIL PUMP ASSY |
1 |
| 30 |
PAF40-05100501EI |
892267521 |
RUBBER SLEEVE,OIL PUMP |
1 |
| 31 |
PAF40-05100504EI |
892267510 |
PADDING BLOCK, OIL PUMP |
1 |
| 32 |
PAF40-05100503EI |
892267523 |
RUBBER PAD, OIL PUMP |
1 |
| 33 |
PAF40-05100502EI |
892267534 |
FILTER NET, OIL PUMP |
1 |
| 34 |
PAF40-05100704EI |
892267530 |
SEAL, OIL CAP |
1 |
| 35 |
PAF40-05100701EI |
892267A54 |
OIL CAP, ELECTRIC PUMP |
1 |
| 36 |
PAF25-05090005 |
65W-86129-10 |
BUSHING, DAMPER |
3 |
| 37 |
PAF25-05090004 |
65W-85547-00 |
DAMPER |
3 |
| 38 |
PAF40-05100800EI |
892267A55 |
COOLER, FUEL |
1 |
| 39 |
PAGB/T97.1-6 |
92990-06600-00 |
WASHER 6 |
1 |
| 40 |
PAGB/T5783-M6x25 |
10-82500925 |
BOLT M6x25 |
4 |
| 41 |
PAGB/T96-6 |
|
BIG WASHER 6 |
3 |
| 42 |
PAF40-05100703EI |
892267506 |
DRAIN BOLT, OIL CUP |
1 |
| Number: |
Order number: |
OEM: |
Description: |
Quantity: |
| 1 |
PAF40-05000069EI |
 |
AIR PIPE C |
1 |
| 2 |
PAT5-04000200 |
 |
CHECK VALVE |
1 |
| 3 |
PAF40-05000070EI |
 |
AIR PIPE D |
2 |
| 4 |
PAF15-05000011 |
688-24378-00 |
THREE WAY |
1 |
| 5 |
PAF40-05000051EI |
 |
AIR PIPE B |
1 |
| 6 |
PAF40-05100000EI |
 |
OIL PUMP ASSY |
1 |
| 7 |
PAF40-05010400EI |
 |
JOINT ASSY, OIL PUMP |
1 |
| 8 |
PAGB/T3452.1-15.8x3.1 |
 |
O-RING 15.8x3.1 |
1 |
| 9 |
PAF40-05100100EI |
892267T57 |
BODY ASSY, OIL PUIIP |
1 |
| 10 |
PAF40-05100100EI |
 |
SINGLE LUG CLAMP |
4 |
| 11 |
PAF40-05100010EI |
 |
SHAPED TUBE A, OIL PUMP |
1 |
| 12 |
PAF40-05100010EI |
 |
SHAPED TUBE B, OIL PUMP |
1 |
| 13 |
PAF40-05100202EI |
883220 |
CAP, DETECTION VALVE |
1 |
| 14 |
PAF40-05100201EI |
 |
DETECTION VALVE, OIL PUMP |
1 |
| 15 |
PAF40-05100600EI |
 |
PRESSURE REGULATOR VALVBE |
1 |
| 16 |
PAF40-05100601EI |
 |
O-RING, PRESSURE REGULATOR VALVE |
1 |
| 17 |
PAF40-05100600-1EI |
 |
WASHER, PRESSURE REGULATOR VALVE |
2 |
| 18 |
PAF40-05100602EI |
 |
CONDUIT TUBE |
1 |
| 19 |
PAF40-05100603EI |
 |
PLATE, PRESSURE REGULATOR VALVE |
1 |
| 20 |
PAGB/T818-M5x12 |
97885-05012 |
SCREW M5x12 |
2 |
| 21 |
PAGB/T818-M4x16 |
 |
SCREW M4x16 |
5 |
| 22 |
PAGB/T93-4 |
 |
SPRING WASHER 4 |
5 |
| 23 |
PAF40-05100301EI |
892267A52 |
NEEDLE VALVE |
1 |
| 24 |
PAF40-05100302EI |
 |
CLAMP SPRING, NEEDLE VALVE |
1 |
| 25 |
PAF40-05100003EI |
 |
BAFFLE PLATE |
1 |
| 26 |
PAGB/T818-M4x8 |
 |
SCREW M4x8 |
4 |
| 27 |
PAF40-05100001EI |
892267527 |
FLOATER |
1 |
| 28 |
PAF40-05100002EI |
892267528 |
PIN, FLOATER |
1 |
| 29 |
PAF40-05100500EI |
892267A51 |
OIL PUMP ASSY |
1 |
| 30 |
PAF40-05100501EI |
892267521 |
RUBBER SLEEVE,OIL PUMP |
1 |
| 31 |
PAF40-05100504EI |
892267510 |
PADDING BLOCK, OIL PUMP |
1 |
| 32 |
PAF40-05100503EI |
892267523 |
RUBBER PAD, OIL PUMP |
1 |
| 33 |
PAF40-05100502EI |
892267534 |
FILTER NET, OIL PUMP |
1 |
| 34 |
PAF40-05100704EI |
892267530 |
SEAL, OIL CAP |
1 |
| 35 |
PAF40-05100701EI |
892267A54 |
OIL CAP, ELECTRIC PUMP |
1 |
| 36 |
PAF25-05090005 |
65W-86129-10 |
BUSHING, DAMPER |
3 |
| 37 |
PAF25-05090004 |
65W-85547-00 |
DAMPER |
3 |
| 38 |
PAF40-05100800EI |
892267A55 |
COOLER, FUEL |
1 |
| 39 |
PAGB/T97.1-6 |
92990-06600-00 |
WASHER 6 |
1 |
| 40 |
PAGB/T5783-M6x25 |
10-82500925 |
BOLT M6x25 |
4 |
| 41 |
PAGB/T96-6 |
 |
BIG WASHER 6 |
3 |
| 42 |
PAF40-05100703EI |
892267506 |
DRAIN BOLT, OIL CUP |
1 |
