Cylinder & Crankcase

Yamaha Parsun Outer Cover, Exhaust.jpg

Nummer: Bestelnummer: OEM: Omschrijving:
1 PAF25-05010000 65W-15100-00-94 CRANKCASE ASSY
2 PAF25-00000014 93608-12063 PIN, DOWEL
3 PAGB/T5782-2000   BOLT, HEXAGON
4 PAGB/T5782-2000   BOLT, HEXAGON
5 PAF25-05000007 65W-15121-00 CRANKCASE
6 PAGB/T3452.1-1992 65W-15663-00 SEAL
7 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
8 PAF25-05010108 65W-11169-00 GASKET ,BREATHER COVER
9 PAF25-05010109 65W-11168-00 COVER,BREATHER
10 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
11 PAF25-05010106 65W-11119-00 HANGER,ENGINE
12 PAGB/T5782-2000   BOLT, HEXAGON
13 PAF15-04000002 90340-14M00 BOLT,OIL DRAIN
14 PAF15-04000003 90430-14115 WASHER
15 PAF25-00000013 65W-11351-00 GASKET,ENGINE
16 PAF4-04000030 90467-09M09 SPRING,FUEL PIPE’’B’’
17 PAF25-05000100 5GH-13440-00 OIL CLEANER
18 PAF4-04000036 68D-E1168-00 THERMOSTAT
19 PAF15-07010022 62Y-12414-00 GASKET, THERMOSTAT
20 PAF15-07010021 6H3-12413-00-00 COVER, THERMOSTAT
21 PAGB/T5783-2000 68D-E5362-00 BOLT
22 PAGB/T97.1-85 66M-11327-00-94 WASHER 6
23 PAGB/T97.1-85 66M-11327-00-94 WASHER 8
24 PAF25-05010113 62Y-11372-01 NIPPLE,HOSE
25 PAF25-05010107 65W-13286-00 CLEANER
26 PAF25-05010112 65W-41113-00-94 OUTER COVER, EXHAUST
27 PAF25-03000008 90445-09068, 90445-092K100 HOSE
28 PAHT-2.5x60 61A-14455-00-00 CLAMP
29 PAF15-05000011 688-24378-00 THREE-WAY PIPE
30 PAF25-03000011 90445-09105, 90445-092K1 HOSE
31 PAF25-03000009 90445-09010, 90445-09095 HOSE
32 PAF15-07010003 90401-20M00 BOLT, UNION
33 PAF25-05010111 65W-41114-00 GASKET, EXHAUST OUTER COVER
34 PAF25-05050100 65W-11111-02-94 CYLINDER ASSY
35 PAF25-00000014 93608-12063 PIN,DOWEL
36 PAF25-05040000 65W-11181-10 GASKET , CYLINDER HEAD
37 PAF25-05050104   VALVE GUIDE BUSH
38 PAF15-07040105   CIRCLIP, GUIDE BUSH
39 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
40 PAF25-05000002 90119-09M00 BOLT,FLANGE
41 PAF25-05000005 65W-11191-00-1S, 65W-11191-00-94 COVER,CYLINDER HEAD
42 PAF25-05000004 65W-11356-00 SEAL,CYLINDER COVER
43 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
44 PAGB/T97.1-85 66M-11327-00-94 WASHER,PLATE
45 PAF15-07050004 69M-E5363-00 PLUG,OIL
46 PAJASO F404 31-025 93210-24800-00 O-RING
47 PAF25-05050007 90430-06014 GASKET
48 PAF25-05050006 90109-06M65 BOLT
49 PAF25-02010005 62Y-11325-00 ANODE
50 PAF15-07010009 66M-11328-00 GROMMET,ANODE
51 PAF15-07010011 66M-11327-00-94 COVER, ANODE
52 PAF15-07010012 66M-12535-00 PLATE,ANODE
53 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
54 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
55 PAGB/T97.1-85 66M-11327-00-94 WASHER,PLATE
56 PAF25-05000003   WASHER,PLATE
57 PAF25-08000005   SIGN 5
58 PAGB/T5783-2000 68D-E5362-00 BOLT
View as Grid List

Items 1-24 of 33

Page
per page
Set Descending Direction
  1. Add to Wish List
    Yamaha / Mercury / Parsun Cylinder Gasket F20 / F25 / T25 / FT25 (65W-11351-10-00)
    Yamaha / Mercury / Parsun Cylinder Gasket F20 / F25 / T25 / FT25 (65W-11351-10-00)
    As low as €39.95 €33.02
  2. Add to Wish List
    Yamaha/Mercury/Mariner/Parsun Plate Anode F9.9 (2004-06), F13.5 (2003-06), F15 (2003-07) (66M-12535-00, 855779)
    Yamaha/Mercury/Mariner/Parsun Plate Anode F9.9 (2004-06), F13.5 (2003-06), F15 (2003-07) (66M-12535-00, 855779)
    As low as €5.95 €4.92
  3. Add to Wish List
    Yamaha/Mercury/Mariner/Parsun Cover, Anode F9.9 (2004-06), F13.5 (2003-06), F15 (2003-07) (855776, 66M-11327-00-94)
    Yamaha/Mercury/Mariner/Parsun Cover, Anode F9.9 (2004-06), F13.5 (2003-06), F15 (2003-07) (855776, 66M-11327-00-94)
    As low as €10.95 €9.05
  4. Add to Wish List
    Yamaha/Mercury/Parsun Grommet, Anode F9.9/F13.5/F15/F20/F25 hp (66M-11328-00, 25-825040)
    Yamaha/Mercury/Parsun Grommet, Anode F9.9/F13.5/F15/F20/F25 hp (66M-11328-00, 25-825040)
    As low as €4.95 €4.09
  5. Add to Wish List
    Yamaha / Mercury / Parsun Bolt FT, F20, F25 (ALL) (1998-08) 90109-06M65 10-827607
    Yamaha / Mercury / Parsun Bolt FT, F20, F25 (ALL) (1998-08) 90109-06M65 10-827607
    As low as €12.95 €10.70
  6. Add to Wish List
    Yamaha / Mercury / Parsun Gasket FT, F20, F25 (ALL) (1998-08) (90430-06014, 27-827610)
    Yamaha / Mercury / Parsun Gasket FT, F20, F25 (ALL) (1998-08) (90430-06014, 27-827610)
    As low as €4.95 €4.09
  7. Add to Wish List
    Yamaha / Mercury / Parsun Cover Cylinder Head FT, F20, F25 (ALL) (1998-08) (65W-11191-00-94, 830272A1)
    Yamaha / Mercury / Parsun Cover Cylinder Head FT, F20, F25 (ALL) (1998-08) (65W-11191-00-94, 830272A1)
    As low as €40.95 €33.84
  8. Add to Wish List
    Yamaha / Mercury / Parsun Bolt flange FT, F20, F25 (ALL) (1998-08) 90119-09M00 10-82503395
    Yamaha / Mercury / Parsun Bolt flange FT, F20, F25 (ALL) (1998-08) 90119-09M00 10-82503395
    As low as €4.95 €4.09
  9. Add to Wish List
    Yamaha / Mercury / Parsun Cylinder assy FT, F20, F25 (ALL) (1998-08) 65W-11111-02-94 830271T2
    Yamaha / Mercury / Parsun Cylinder assy FT, F20, F25 (ALL) (1998-08) 65W-11111-02-94 830271T2
    As low as €395.00 €395.00
  10. Add to Wish List
    Yamaha/Mercury/Parsun Bolt Union F9.9/F13.5/F15/F20/F25 (90401-20M00, 822625)
    Yamaha/Mercury/Parsun Bolt Union F9.9/F13.5/F15/F20/F25 (90401-20M00, 822625)
    As low as €17.95 €14.83
  11. Add to Wish List
    Yamaha / Parsun Hose FT, F20, F25 (ALL) (1998-08) 90445-09095
    Yamaha / Parsun Hose FT, F20, F25 (ALL) (1998-08) 90445-09095
    As low as €12.95 €10.70
  12. Add to Wish List
    Yamaha / Mercury / Parsun Clamp Fastener FT, F20, F25 (ALL) (1998-08) 25HP J/JEO/ESH - 30HP D/DEO/DETO - ELH /ELA DMHO/DMSH - ERZ/DEL - MLH (1986-2013) 90465-11M10, 90467-06016
    Yamaha / Mercury / Parsun Clamp Fastener FT, F20, F25 (ALL) (1998-08) 25HP J/JEO/ESH - 30HP D/DEO/DETO - ELH /ELA DMHO/DMSH - ERZ/DEL - MLH (1986-2013) 90465-11M10, 90467-06016
    As low as €4.95 €4.09
  13. Add to Wish List
    Yamaha / Parsun Hose FT, F20, F25 (ALL) (1998-08) 90445-09068
    Yamaha / Parsun Hose FT, F20, F25 (ALL) (1998-08) 90445-09068
    As low as €4.95 €4.09
  14. Add to Wish List
    Yamaha / Mercury / Parsun Outer cover exhaust FT, F20, F25 (ALL) (1998-08) 65W-41113-01-94 883336T1
    Yamaha / Mercury / Parsun Outer cover exhaust FT, F20, F25 (ALL) (1998-08) 65W-41113-01-94 883336T1
    As low as €39.95 €33.02
  15. Add to Wish List
    Yamaha / Mercury / Parsun Cleaner FT, F20, F25 (ALL) (1998-08) 65W-13286-00, 35-8548091
    Yamaha / Mercury / Parsun Cleaner FT, F20, F25 (ALL) (1998-08) 65W-13286-00, 35-8548091
    As low as €6.95 €5.74
  16. Add to Wish List
    Yamaha / Mercury / Mariner / Parsun Cover Thermostat 9.9 to 70 hp (6H3-12413-00-9M, 8250311)
    Yamaha / Mercury / Mariner / Parsun Cover Thermostat 9.9 to 70 hp (6H3-12413-00-9M, 8250311)
    As low as €14.95 €14.95
  17. Add to Wish List
    Yamaha/Mercury/Mariner/Parsun Thermostaat Gasket 9.9 to 70 hp (62Y-12414-00, 62Y-12414-00-00, 27-824853)
    Yamaha/Mercury/Mariner/Parsun Thermostaat Gasket 9.9 to 70 hp (62Y-12414-00, 62Y-12414-00-00, 27-824853)
    As low as €7.95 €6.57
  18. Add to Wish List
    Yamaha / Mercury / Parsun Hanger, Engine FT, F20, F25 (ALL) (1998-08) 66W-11119-00 8525601
    Yamaha / Mercury / Parsun Hanger, Engine FT, F20, F25 (ALL) (1998-08) 66W-11119-00 8525601
    As low as €12.50 €12.50
  19. Add to Wish List
    Yamaha / Mercury / Parsun Cover breather FT, F20, F25 (ALL) (1998-08) 65W-11168-00 832734A2
    Yamaha / Mercury / Parsun Cover breather FT, F20, F25 (ALL) (1998-08) 65W-11168-00 832734A2
    As low as €15.95 €13.18
  20. Add to Wish List
    Yamaha / Mercury / Parsun Gasket breathercover FT, F20, F25 (ALL) (1998-08) 65W-11169-00 27-8547801
    Yamaha / Mercury / Parsun Gasket breathercover FT, F20, F25 (ALL) (1998-08) 65W-11169-00 27-8547801
    As low as €7.50 €7.50
  21. Add to Wish List
    Yamaha/Mercury/Parsun Seal FT, F20, F25 (ALL) (1998-08) (25-854722, 65W-15663-00)
    Yamaha/Mercury/Parsun Seal FT, F20, F25 (ALL) (1998-08) (25-854722, 65W-15663-00)
    As low as €4.95 €4.09
  22. Add to Wish List
    Yamaha / Mercury / Parsun Crankcase FT, F20, F25 (ALL) (1998-08) 65W-15121-00 8556692
    Yamaha / Mercury / Parsun Crankcase FT, F20, F25 (ALL) (1998-08) 65W-15121-00 8556692
    As low as €41.95 €34.67
  23. Add to Wish List
    Yamaha / Parsun / Mercury Pin dowel FT, F20, F25 (ALL) (1998-08) 99530-08012 17-825010
    Yamaha / Parsun / Mercury Pin dowel FT, F20, F25 (ALL) (1998-08) 99530-08012 17-825010
    As low as €4.95 €4.09
  24. Add to Wish List
    Yamaha / Mercury Crankcase Assy FT, F20, F25 (ALL) (1998-08) 65W-15100-00-94 2806-830267T3
    Yamaha / Mercury Crankcase Assy FT, F20, F25 (ALL) (1998-08) 65W-15100-00-94 2806-830267T3
    As low as €475.00 €475.00
View as Grid List

Items 1-24 of 33

Page
per page
Set Descending Direction

Yamaha Parsun Outer Cover, Exhaust.jpg

Number: Order number: OEM: Description:
1 PAF25-05010000 65W-15100-00-94 CRANKCASE ASSY
2 PAF25-00000014 93608-12063 PIN, DOWEL
3 PAGB/T5782-2000   BOLT, HEXAGON
4 PAGB/T5782-2000   BOLT, HEXAGON
5 PAF25-05000007 65W-15121-00 CRANKCASE
6 PAGB/T3452.1-1992 65W-15663-00 SEAL
7 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
8 PAF25-05010108 65W-11169-00 GASKET ,BREATHER COVER
9 PAF25-05010109 65W-11168-00 COVER,BREATHER
10 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
11 PAF25-05010106 65W-11119-00 HANGER,ENGINE
12 PAGB/T5782-2000   BOLT, HEXAGON
13 PAF15-04000002 90340-14M00 BOLT,OIL DRAIN
14 PAF15-04000003 90430-14115 WASHER
15 PAF25-00000013 65W-11351-00 GASKET,ENGINE
16 PAF4-04000030 90467-09M09 SPRING,FUEL PIPE’’B’’
17 PAF25-05000100 5GH-13440-00 OIL CLEANER
18 PAF4-04000036 68D-E1168-00 THERMOSTAT
19 PAF15-07010022 62Y-12414-00 GASKET, THERMOSTAT
20 PAF15-07010021 6H3-12413-00-00 COVER, THERMOSTAT
21 PAGB/T5783-2000 68D-E5362-00 BOLT
22 PAGB/T97.1-85 66M-11327-00-94 WASHER 6
23 PAGB/T97.1-85 66M-11327-00-94 WASHER 8
24 PAF25-05010113 62Y-11372-01 NIPPLE,HOSE
25 PAF25-05010107 65W-13286-00 CLEANER
26 PAF25-05010112 65W-41113-00-94 OUTER COVER, EXHAUST
27 PAF25-03000008 90445-09068, 90445-092K100 HOSE
28 PAHT-2.5x60 61A-14455-00-00 CLAMP
29 PAF15-05000011 688-24378-00 THREE-WAY PIPE
30 PAF25-03000011 90445-09105, 90445-092K1 HOSE
31 PAF25-03000009 90445-09010, 90445-09095 HOSE
32 PAF15-07010003 90401-20M00 BOLT, UNION
33 PAF25-05010111 65W-41114-00 GASKET, EXHAUST OUTER COVER
34 PAF25-05050100 65W-11111-02-94 CYLINDER ASSY
35 PAF25-00000014 93608-12063 PIN,DOWEL
36 PAF25-05040000 65W-11181-10 GASKET , CYLINDER HEAD
37 PAF25-05050104   VALVE GUIDE BUSH
38 PAF15-07040105   CIRCLIP, GUIDE BUSH
39 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
40 PAF25-05000002 90119-09M00 BOLT,FLANGE
41 PAF25-05000005 65W-11191-00-1S, 65W-11191-00-94 COVER,CYLINDER HEAD
42 PAF25-05000004 65W-11356-00 SEAL,CYLINDER COVER
43 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
44 PAGB/T97.1-85 66M-11327-00-94 WASHER,PLATE
45 PAF15-07050004 69M-E5363-00 PLUG,OIL
46 PAJASO F404 31-025 93210-24800-00 O-RING
47 PAF25-05050007 90430-06014 GASKET
48 PAF25-05050006 90109-06M65 BOLT
49 PAF25-02010005 62Y-11325-00 ANODE
50 PAF15-07010009 66M-11328-00 GROMMET,ANODE
51 PAF15-07010011 66M-11327-00-94 COVER, ANODE
52 PAF15-07010012 66M-12535-00 PLATE,ANODE
53 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
54 PAGB/T5783-2000 68D-E5362-00 BOLT, HEXAGON
55 PAGB/T97.1-85 66M-11327-00-94 WASHER,PLATE
56 PAF25-05000003   WASHER,PLATE
57 PAF25-08000005   SIGN 5
58 PAGB/T5783-2000 68D-E5362-00 BOLT
