F200 / F225 / F250 V6 4-Stroke 2.6L

Nummer:	Bestelnummer:	Yamaha OEM:	Omschrijving
1	REC416-A20	64D-45300-01-8D	LOWER UNIT ASSY
1	REC416-A25	64D-45300-21-8D	LOWER UNIT ASSY
2	REC63P-45501-00	63P-45501-00	DRIVE SHAFT 20”
2	REC63P-45501-10	63P-45501-10	DRIVE SHAFT 25”
3	REC93210-58677	93210-58677	O-RING
4	REC6G5-45536-01	6G5-45536-01	SLEEVE
5	REC93315-430V5	93315-430V5	BEARING
6	REC6E5-45331-00-94	6E5-45331-00-94	HOUSSING
7	REC93101-28M16	93101-28M16	OIL SEAL
8	REC6E5-45587-01	6E5-45587-01	SHIM
9	REC93341-930U0	93341-930U0	BEARING
10	GLM84215	93210-54534	O-RING
11	REC6G5-45567-01	6G5-45567-01	SHIM
12	CM6J9-45371-01	6J9-45371-01	ANODE
13	REC6G5-45551-00	6G5-45551-01	GEAR
14	REC90170-16M01	90170-16M01	NUT
15	REC93332-000V3	93332-000V3	BEARING
16	REC6G5-45631-00	6G5-45631-00	GEAR F.W
17
18	REC6E5-45631-00	6E5-45631-01	CLUTCH
19	REC90250-08M07	90250-08M07	PIN
20	REC6E5-45633-01	6E5-45633-01	SPRING
21	REC6J9-45611-00	6J9-45611-01	PROPELLER SHAFT
22	REC90201-30M92	90201-30M92	WASHER
23	REC6G5-45570-00	6G5-45570-02	GEAR R.V.
24	REC93210-97M55	93210-97M55	O-RING
25	REC93306-209U0	93306-209U0	BEARING
26		6J9-45332-00-94	GEAR HOUSING
27	REC93315-430U8	93315-430U8	BEARING
28	REC93101-30M17	91301-30M17	OIL SEAL
29	REC6G5-45383-01	6G5-45383-01	WASHER
30	REC6G5-45384-00	6G5-45384-00	NUT
31	REC93315-425V3	93315-425V3	BEARING
32	REC6E5-45344-00	6E5-45344-00	OIL SEAL
33	REC6E5-44315-00	6E5-44315-A0	GASKET
34	REC6G5-44323-00	6G5-44323-00	Outer plate
35	REC6E5-44352-01	6E5-44352-00	IMPELLER
36	REC6E5-44322-00/41	6E5-44322-00	INSERT CUP – MODERN
37	REC93210-86M38	93210-86M38	O-RING
38	REC93210-37M67	93210-37M67	O-RING
39	REC6E5-44311-00	6E5-44311-00	W.P. HOUSING –MODERNO
40	REC97080-08045	97080-08045	BOLT
41	GLM38301	6E5-44366-00	DAMPER
42	REC6E5-44312-00	6E5-44312-00	CAP
43	GLM38300	6E5-44365-00	SEAL
44	REC90430-08020	90430-08020	GASKET
45	REC688-45341-00	688-45341-00	PLUG
46	REC90340-08014	90340-08M04	PLUG
47	REC688-45997-00	688-45997-01	SPACER
48	GLM21221	92990-18200	WASHER
49	REC90171-18M04	90171-18M04	NUT
50	REC91490-40030	91490-40030	PIN
51	REC6E5-45987-00	6E5-45987-00	Spacer
53	REC6G5-45576-10	6G5-45576-00	WASHER
54	REC93511-32027	93511-32027	BALL
55	REC90501-16M37	90501-16M37	SPRING
56	REC93503-16003	93503-16003	BALL
57	REC93507-32031	93507-32031	BALL
58	REC6E5-45634-01	6E5-45634-01	SHIFT SLIDE
59	REC6E5-45641-03	6E5-45641-03	SHIFTER
60	REC6E5-45321-00	6E5-45321-00	PLATE
61	REC6G5-44150-02	6G5-44150-02	SHIFT SHAFT
62	REC90501-11M18	90501-11M18	SPRING
63	REC6E5-45378-00	6E5-45378-00	Nipple hose
