F200 / F225 / F250 V6 4-Stroke 2.6L
| Nummer: |
Bestelnummer: |
Yamaha OEM: |
Omschrijving |
| 1 |
REC416-A20 |
64D-45300-01-8D |
LOWER UNIT ASSY |
| 1 |
REC416-A25 |
64D-45300-21-8D |
LOWER UNIT ASSY |
| 2 |
REC63P-45501-00 |
63P-45501-00 |
DRIVE SHAFT 20” |
| 2 |
REC63P-45501-10 |
63P-45501-10 |
DRIVE SHAFT 25” |
| 3 |
REC93210-58677 |
93210-58677 |
O-RING |
| 4 |
REC6G5-45536-01 |
6G5-45536-01 |
SLEEVE |
| 5 |
REC93315-430V5 |
93315-430V5 |
BEARING |
| 6 |
REC6E5-45331-00-94 |
6E5-45331-00-94 |
HOUSSING |
| 7 |
REC93101-28M16 |
93101-28M16 |
OIL SEAL |
| 8 |
REC6E5-45587-01 |
6E5-45587-01 |
SHIM |
| 9 |
REC93341-930U0 |
93341-930U0 |
BEARING |
| 10 |
GLM84215 |
93210-54534 |
O-RING |
| 11 |
REC6G5-45567-01 |
6G5-45567-01 |
SHIM |
| 12 |
CM6J9-45371-01 |
6J9-45371-01 |
ANODE |
| 13 |
REC6G5-45551-00 |
6G5-45551-01 |
GEAR |
| 14 |
REC90170-16M01 |
90170-16M01 |
NUT |
| 15 |
REC93332-000V3 |
93332-000V3 |
BEARING |
| 16 |
REC6G5-45631-00 |
6G5-45631-00 |
GEAR F.W |
| 17 |
|
|
|
| 18 |
REC6E5-45631-00 |
6E5-45631-01 |
CLUTCH |
| 19 |
REC90250-08M07 |
90250-08M07 |
PIN |
| 20 |
REC6E5-45633-01 |
6E5-45633-01 |
SPRING |
| 21 |
REC6J9-45611-00 |
6J9-45611-01 |
PROPELLER SHAFT |
| 22 |
REC90201-30M92 |
90201-30M92 |
WASHER |
| 23 |
REC6G5-45570-00 |
6G5-45570-02 |
GEAR R.V. |
| 24 |
REC93210-97M55 |
93210-97M55 |
O-RING |
| 25 |
REC93306-209U0 |
93306-209U0 |
BEARING |
| 26 |
|
6J9-45332-00-94 |
GEAR HOUSING |
| 27 |
REC93315-430U8 |
93315-430U8 |
BEARING |
| 28 |
REC93101-30M17 |
91301-30M17 |
OIL SEAL |
| 29 |
REC6G5-45383-01 |
6G5-45383-01 |
WASHER |
| 30 |
REC6G5-45384-00 |
6G5-45384-00 |
NUT |
| 31 |
REC93315-425V3 |
93315-425V3 |
BEARING |
| 32 |
REC6E5-45344-00 |
6E5-45344-00 |
OIL SEAL |
| 33 |
REC6E5-44315-00 |
6E5-44315-A0 |
GASKET |
| 34 |
REC6G5-44323-00 |
6G5-44323-00 |
Outer plate |
| 35 |
REC6E5-44352-01 |
6E5-44352-00 |
IMPELLER |
| 36 |
REC6E5-44322-00/41 |
6E5-44322-00 |
INSERT CUP – MODERN |
| 37 |
REC93210-86M38 |
93210-86M38 |
O-RING |
| 38 |
REC93210-37M67 |
93210-37M67 |
O-RING |
| 39 |
REC6E5-44311-00 |
6E5-44311-00 |
W.P. HOUSING –MODERNO |
| 40 |
REC97080-08045 |
97080-08045 |
BOLT |
| 41 |
GLM38301 |
6E5-44366-00 |
DAMPER |
| 42 |
REC6E5-44312-00 |
6E5-44312-00 |
CAP |
| 43 |
GLM38300 |
6E5-44365-00 |
SEAL |
| 44 |
REC90430-08020 |
90430-08020 |
GASKET |
| 45 |
REC688-45341-00 |
688-45341-00 |
PLUG |
| 46 |
REC90340-08014 |
90340-08M04 |
PLUG |
| 47 |
REC688-45997-00 |
688-45997-01 |
SPACER |
| 48 |
GLM21221 |
92990-18200 |
WASHER |
| 49 |
REC90171-18M04 |
90171-18M04 |
NUT |
| 50 |
REC91490-40030 |
91490-40030 |
PIN |
| 51 |
REC6E5-45987-00 |
6E5-45987-00 |
Spacer |
| 53 |
REC6G5-45576-10 |
6G5-45576-00 |
WASHER |
| 54 |
REC93511-32027 |
93511-32027 |
BALL |
| 55 |
REC90501-16M37 |
90501-16M37 |
SPRING |
| 56 |
REC93503-16003 |
93503-16003 |
BALL |
| 57 |
REC93507-32031 |
93507-32031 |
BALL |
| 58 |
REC6E5-45634-01 |
6E5-45634-01 |
SHIFT SLIDE |
| 59 |
REC6E5-45641-03 |
6E5-45641-03 |
SHIFTER |
| 60 |
REC6E5-45321-00 |
6E5-45321-00 |
PLATE |
| 61 |
REC6G5-44150-02 |
6G5-44150-02 |
SHIFT SHAFT |
| 62 |
REC90501-11M18 |
90501-11M18 |
SPRING |
| 63 |
REC6E5-45378-00 |
6E5-45378-00 |
Nipple hose |
